Cretex External X-85 Seal

Get the best performance and save labor costs over the long haul with Cretex’s External X-85 Seals. High-performance watertight seal used between the manhole casting and concrete cone. Cretex’s state-of-the art technology combines all of the advantages of a mechanical seal in a more economical, easy to use option.

The top band of the seal is designed to add compression to the inner rubber sealing fins, uniformly filling the annular space between the frame and the cone. The resulting seal forms a watertight barrier around the top, bottom and outer edges of the frame’s base flange. Cretex’s unique “C”-shape band mechanically locks the seal on the manhole casting for lasting performance. Our high-performance seal requires no primers, torches or special tools to create a watertight barrier. The securing band adds additional compression to the sealing fins, instantly filling any minor voids or irregularities.

 X-85 External Seals Advantage

  • Provides flexible, watertight seal.
  • Easy installation.
  • No primers or torches needed.
  • No special tools required.
  • Can span up to 12″ of adjustment without an extension.
  • Can accommodate offsets and diameter differentials.
  • Can be used for both above and below grade applications.
  • Cost effective option to classic external chimney seal.

Let Cretex help you seal it successfully with an external seal. Call Cretex at 800-345-3764.

Cretex Customer Testimonials

“My career in Wastewater for the City Of Kerrville began early 2001. During this 15 plus year employment as Collection Foreman, I have seen every type of adjustable ring come and go. From concrete to plastic and even the vulcanized rubber rings. Nothing has been easier, quicker or less intensive on my manpower as the Pro-Ring. They have stood up to side streets and highways alike with a ZERO failure rate.  And with the extreme light weight, loading and setting them is no longer a hassle. Thanks Pro Ring!”

Matthew Zapata, Water Reclamation Collection Foreman - City of Kerrville, TX

“Bill just wanted to send you a short note about Pro-Ring.  As you know we had a trial project with these in the Pima County area with a local contractor.  The product ordering experience was great and product shipped in a good, timely manner.  The success of that project has been a determining factor for us at Dana Kepner Tucson that we have decided to stock the various Pro-Rings keeping an inventory for our contractors.  As I stated–the ordering experience was great with the stock inventory being ship quickly.  We look forward to this product being a mainstay inventory and look forward to its usages in the Pima County areas and others.  We feel this product will be a profitable experience for Dana Kepner and look forward to future business with Pro Ring.”

Terry Spencer, Branch Manager - Dana Kepner - Tucson, AZ

“Also, for reference on the PRO-RING’s as to the cost benefit – PRO-RING at $90 ea. Vs. concrete grade rings at $20 each. Yesterday afternoon my crew used the PRO-RING’s to replace and adjust two manhole castings. From the time they starting cutting the asphalt, removed it, removed the old castings, set the PRO-RING’s to grade, bolted the new castings in, backfilled, compacted and paved – 1 hour.   Job done and we don’t have to go back.  With the concrete rings, you can never really get the angle and grade set nice without mixing up concrete and tapping it correct, then you need to wait for the concrete to set up, at least an hour, backfill, then grout in the concrete riser rings.   Even using quickset, once you put a compactor to the gravel around it, you are hoping the concrete doesn’t move.  It was 2hrs per manhole with that system.   Crew cost is pushing $300+/hr with overhead and equipment.  More if you need traffic control/flagging on a busier roadway, not to mention the longer you are out there the more you are disrupting traffic.  The crews love the PRO-RING system. It’s fast, easy and leaves a perfect finish to grade.  It’s light weight and easy to install.”

James Storey, Utility Supervisor - District of Maple Ridge, BC
